──Aug 20 , 2021The installation and construction process of Weili Huang stainless steel columns

  The material of stainless steel columns is mostly stainless steel201,304It is widely used as the support column for stairs, railings, handrails and handrails. The surface is generally frosted brushed or gold-plated. The main plate of the column is generally selected6-15MMThick, the market specifications are mostly of height850*50MMor1050*50MMAdd accessories such as glass grippers. The main body of the column is cut out by precise cutting equipment and can be cut into various shapes. Then, it undergoes sheet metal processing. Most of the glass connection fasteners are cast.

  The installation and construction process of Weili Huang stainless steel columns
  (1Project process: Installation of embedded parts, layout, installation of column handrails, connection with columns, grinding and polishing
  (2Installation of embedded parts: The installation of embedded parts for the staircase railing can only be done by the post-embedded method. The method involves using expansion bolts and steel plates to make post-connected parts. First, lay out the lines on the civil construction base, then drill holes on the staircase floor with an impact drill, tighten the bolts and weld the nuts and screws together to prevent the nuts and steel plates from loosening.
  (3Layout: Due to the above-mentioned post-installation embedded parts construction, errors may occur. Before the installation of the columns, the layout should be redone to determine the position of the embedded plates and the accuracy of the welded vertical rods. It should be ensured that all the columns are fully located on the steel plates and can be welded around.
  (4Grinding and polishing: After all the welding is completed, use a portable grinding wheel grinder to smooth and sand out the weld seams until they are no longer visible.
  (5The connection between the handrail and the column: Before installation, the column is marked with an extended line. According to the inclination Angle of the staircase and the roundness of the handrail to be used, a groove is processed at the upper end. Then place the handrails directly into the grooves of the columns. The adjacent handrails should be installed and joined accurately, with tight joints.

  The basic requirements for the installation personnel of Weili Huang stainless steel columns
  The installation of stainless steel bridge guardrails involves many considerations. In current engineering construction, the basic requirements for the installers of stainless steel railing posts are also very comprehensive. It is required that the installers possess certain qualities before they can carry out the installation. It is essential to have a high level of familiarity with the engineering drawings. When we observe the installation process of these stainless steel railings, technical briefings are also very important. If the installers have no understanding of the drawings at all, the technical process briefings will also be very troublesome.

  When installing stainless steel railings, if it is done at the location where there are already railings, it should also be noted that it is much easier to do so after the original railings have been completely removed. For example, when drilling holes, it will have a significant impact. In addition, before construction, it is necessary to check whether the qualification certificates of the welders of the stainless steel columns have expired, and pay attention to the qualifications of the welders.
1
  Foshan Weilihuang Trading Co., Ltd. is a leading manufacturer specializing in the production and sales of international and domestic stainless steel hardware accessories and its own brands. The company is located at Tianjinli Hardware Accessories Center, Lanshi 2nd Road, Chancheng District, Foshan City, Guangdong Province8seat10-12The number (i.e., the main entrance of the market) has an abundant supply of goods, a complete range of varieties, wide coverage, favorable prices, and stable and superior quality!

  The company uses high-quality stainless steel and exquisite craftsmanship to ensure there are no weld marks at the interfaces. Its products feature novel designs, elegant craftsmanship, and long-lasting durability. The company has always adhered to the principle of quality first and reputation first. It is equipped with mature production facilities and has strong technical strength, thus ensuring the quality of its products. The company is willing to make unremitting efforts to join hands with our customers to create a win-win situation and provide high-quality products for our partners.
